Koleba samowyładowcza NTK HD 1100

Description

The NTK HD 1100 self-tipping skip is an advanced solution for companies that need to combine a large loading volume with extreme durability. With a capacity of 1,100 litres and a powerful load rating of 1,500 kg, this model is built for the toughest tasks in steelworks, metal processing plants, sawmills, and construction sites. The HD (Heavy Duty) series is a guarantee that the attachment will not deform, even under intensive use with heavy loads.

Technical parameters and construction of the HD 1100

This model stands out with its massive build, designed for high-load applications. The hopper walls are made of 3mm steel plate, while the base – the load-bearing element of the entire structure – has been reinforced with 4mm thick steel. Despite its large capacity, engineers have managed to maintain optimal proportions. The NTK HD 1100 self-tipping skip has a length of 1,730 mm, a width of 1,420 mm, and a height of 1,165 mm.

The total unladen weight of the container is 189 kg, which testifies to the quantity and quality of the steel used. The top edge features additional wrap-around reinforcement, which stiffens the structure and protects the walls from bending during mechanical loading.

Leak-proof integrity and versatile applications

A key advantage of this model is the double-sided welding of the seams. This technology ensures 100% leak-proof integrity, making this tank a universal solution. It can be used without hesitation to transport:

• Materials dripping with coolant (steel and aluminium swarf),

• Sludges and semi-liquid waste,

• Wet concrete, sand, or gravel,

• Heavy scrap and bulky waste.

Dual discharge mechanism – Comfort and Safety

To maximise warehouse efficiency, the NTK HD 1100 self-tipping skip is equipped with two independent emptying systems:

1. Front Pressure Plate (Automatic mode): Allows for discharge without leaving the forklift cab. The operator presses the pressure plate (located at the front of the skip) against the edge of a waste container, which releases the lock and initiates the tilt.

2. Manual Lever (Manual mode): A lever located on the rear wall (on the forklift carriage side) allows for manual release of the tipping mechanism. This is indispensable for the precise dosing of material.

The system has been designed with ergonomics in mind – after emptying, thanks to proper balancing, the empty container automatically returns to a horizontal position and snaps into the lock.

Why choose a polyurethane coating?

The durability of the HD 1100 model is enhanced by spray-painting with polyurethane paint. Unlike standard anti-corrosion protection, polyurethane creates a hard, glass-like coating. It is highly resistant to mechanical damage, as well as to the effects of oils and greases. The smooth surface facilitates cleaning (“easy-clean”) and prevents wet waste from adhering to the walls.
